AST-BND320-STN

Hot Air Seam Sealing Machine

Technical Specifications

  • Electrical : 220V 50 Hz

  • Power : 4000 W

  • Maximum Sealing Speed : 23 m / dk

  • Maximum Temperature : 750 C

  • Compressed Air : 4-6 bar / 200Lt / min

  • Upper Roller Width : 25.4 mm

  • Down Roller Width : 31 mm

  • Dimension : 1200 x 710 x 1771 mm

  • Weight : 150 kg

  • Optional Roller Size : 8- 40 mm

  • Nozzle Unit : 22 mm

Features

  • It is used for sealing tape on all kinds of fabrics with the help of hot air on seams in order to prevent leakage or increase the strength of ultrasonic welding

  • Perfect result for medical fabrics

  • Touch screen multi-program structure

  • Programmable automatic distance and cutting range, it provides fast operation and standard output

  • The speed of the lower / upper differentials can be adjusted on the screen independently

  • Adjustable tape feeding unit

  • Easy adaptation to the products is provided by the adjustable roller pressure setting

  • High-tech alarm and information system

  • Digital pressure gauges

  • High-tech resistance can be adjusted up to 750 C which shows the fast reaction

  • Adjustable hot air nozzle in 3 axes

Sectors

  • APPAREL

Product Brochure

Request an Offer

First of all thank you for your interest in our products. If you fill in our offer form, we will get back to you as soon as possible. We hope your investment will be beneficial.
